TP-Link Omada DR3220v-4G wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

WAN connection

• Ethernet WAN: Yes
• DSL WAN: Yes
• SIM card slot: No
• 3G/4G USB modem compatibility: Yes
• WAN connection type: RJ-45

Wireless LAN features

• Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
• WLAN data transfer rate (max): 2402 Mbit/s
• Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
• WLAN data transfer rate (first band): 574 Mbit/s
• WLAN data transfer rate (second band): 2402 Mbit/s

Network

• Ethernet LAN: Yes
• Ethernet LAN interface type: Gigabit Ethernet
• Ethernet LAN data rates: 10,100,1000 Mbit/s
• Cabling technology: 10/100/1000Base-T(X)
• Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
• Port triggering: Yes
• Load balancing system: Yes
• Dynamic DNS (DDNS): Yes
• Policy-based routing: Yes
• Static route: Yes
• Built-in FTP server: Yes
• VPN support: IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN

DSL features

• ADSL: Yes
• ADSL2: Yes
• ADSL2+: Yes
• VDSL2: Yes

Ports & interfaces

• Ethernet LAN (RJ-45) ports: 4
• USB port: Yes
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
• RJ-11 ports quantity: 3
• DC-in jack: Yes

Management features

• Web-based management: Yes
• Quality of Service (QoS) support: Yes
• Reset button: Yes
• MU-MIMO technology: Yes

Security

• Security algorithms: WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
• Guest access: Yes
• Access Control List (ACL): Yes
• URL filtering: Yes
• System event log: Yes
• DMZ support: Yes
• Network address translation (NAT): Yes

Protocols

• DHCP client: Yes
• DHCP server: Yes
• Universal Plug and Play (UPnP): Yes
• Voice codecs: G.711a, G.711ulaw, G.722, G.726, G.729ab

Design

• Product type: Tabletop router
• Product colour: Black
• Wall mountable: Yes
• Indication light: Yes
• LED indicators: DSL, LAN, USB, WLAN

Packaging content

• Cables included: LAN (RJ-45), Phone
• AC adapter included: Yes
• Antenna included: Yes

Antenna

• Antenna design: External
• Antenna gain level (max): 4.5 dBi
• Antennas quantity: 3
• Detachable antenna(s): Yes

Power

• Power source type: AC
• Output voltage: 12 V
• Output current: 3.3 A

Operational conditions

• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 10 - 90%
• Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

• Width: 226 mm
• Depth: 131 mm
• Height: 35 mm

Packaging data

• Package type: Box
• Number of products included: 1 pc(s)
