Samsung VM46B-U LCD Indoor

Display

• Display technology: LCD
• Pixel pitch: 0.53 x 0.53 mm
• Display brightness: 500 cd/m²
• Display diagonal: 116.8 cm (46")
• Display resolution: 1920 x 1080 pixels
• HD type: Full HD
• Panel type: IPS
• Aspect ratio: 16:9
• Pixel frequency: 82 MHz
• Contrast ratio (typical): 1200:1
• Contrast ratio (dynamic): 45000:1
• Response time: 0.008 s
• Viewing angle, horizontal: 178°
• Viewing angle, vertical: 178°
• Horizontal scan range: 62.7 - 72.3 kHz
• Vertical scan range: 57 - 63 Hz
• Operating hours (hours/days): 24/7

Design

• Placement supported: Indoor
• Orientation: Horizontal/Vertical
• Bezel width (side): 1.25 mm
• Bezel width (top): 2.25 mm
• Bezel width (bottom): 2.25 mm
• VESA mounting: Yes
• Panel mounting interface: 600 x 400 mm
• Product colour: Black
• Panel colour: Black

Ports & interfaces

• HDMI ports quantity: 2
• HDMI version: 2.0
• DVI port: Yes
• DisplayPorts quantity: 1
• DisplayPort version: 1.2
• Ethernet LAN: Yes
• Ethernet LAN (RJ-45) ports: 1
• RS-232 input ports: 1
• RS-232 output ports: 1
• RS-232C: Yes
• USB port: Yes
• USB ports quantity: 1
• HDCP: Yes
• HDCP version: 2.2
• IR input ports quantity: 1
• Audio input: Yes
• Audio output: Yes

Power

• Power consumption (typical): 160 W
• Energy efficiency scale: A to G
• Energy efficiency class (SDR): G
• Energy consumption (SDR) per 1000 hours: 128 kWh
• AC input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz

Operational conditions

• Operating temperature (T-T): 0 - 40 °C
• Operating relative humidity (H-H): 10 - 90%

Logistics data

• Harmonized System (HS) code: 85285210

Sustainability

• Certification: FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 　 EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14336-1 ( ITE Safety ) / CNS15663 (RoHS)C-Tick (Australia) : AS/NZS CISPR32:2015CCC(China) :GB/T9254-2008, GB17625.1-2012GOST(Russia/CIS) : ROCT CISPR 24-2013/ROCT CISPR 22:2005

Weight & dimensions

• Width: 1022 mm
• Depth: 69.9 mm
• Height: 577 mm
• Weight: 15.7 kg

Packaging data

• Package width: 1193 mm
• Package depth: 257 mm
• Package height: 719 mm
• Package weight: 22.2 kg
