APC RACK PDU BASIC 1 U 16A 230V Power Distribution Unit (PDU) 12 AC outlet(s) 0U/1U Black

APC RACK PDU BASIC 1 U 16A 230V Power Distribution Unit (PDU) 12 AC outlet(s) 0U/1U Black

Part no.AP9559

£304.16ex VAT£364.99 inc VAT
£0.00 £304.16ex VAT£364.99 inc VAT
Sale Sold out
Price shown ex VAT and inc VAT (20%). UK delivery £5.99, free on orders of £50 or more (inc VAT). Delivery details

✓ In stock: UK delivery in 2–4 working days

Buying 5 or more? Get a quote

5.0 on Google

View full details

Overview

Description:

APC Basic Rack PDU, Input : 120, 208, 230V , Input Connection Type : IEC-320 C20 , Cord Length : 8.2 feet ( 2.5 meters ) , Output : 120, 208, 230V , Output Connections : (10)IEC 320 C13, (2)IEC 320 C19

Features: 19 inch Rack-Mountable, Low Cost Power Distribution, Vertical Mounting Capabilities

Includes: Cord Retention Clips, Rack Mounting Brackets, User Manual


Output Voltage(s) (main only) - 120, 208, 230 V

Maximum Total Current Draw per Phase - 16 A

Output Connections - (10)IEC 320 C13; (2)IEC 320 C19

Always on Outlets - 12
Overload Protection

Input:

Nominal input voltage - 120, 208, 230

Input frequency (Hz) - 50/60 Hz

Input Connection Type - IEC-320 C20

Cord Length 8.2 feet ( 2.5 meters )

Acceptable Input Voltage - 90-250 VAC

Maximum Line Current per phase - 16.0 A

Maximum Input Current per phase - 16.0 A

Load Capacity - 3680


Specifications

Design
PDU typesBasic
TypeSingle-phase
Rack capacity0U/1U
MountingHorizontal/Vertical
Product colourBlack
Ports & interfaces
AC outlets quantity12 AC outlet(s)
Power plugC20 coupler
AC outlet typesC13 coupler, C19 coupler
I/O portsOutput Connections - (10)IEC 320 C13; (2)IEC 320 C19 Input Connection Type - IEC-320 C20
Features
Cable length2.5 m
Power
Load capacity3680 VA
Maximum input current per phase16 A
Maximum power3680 W
Operational conditions
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-25 - 65 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Weight & dimensions
Width447 mm
Depth57.2 mm
Height44.5 mm
Weight980 g
Product details
Part numberAP9559
BrandAPC
Supplier descriptionAPC RACK PDU BASIC 1U 16A 208 AND 230V (10)C13 AND (2)C19
EAN0731304123521
