APC Rack PDU, Switched, 2U, 30A, 208V, (16)C13
APC Rack PDU, Switched, 2U, 30A, 208V, (16)C13
Part no.AP7911B
Regular price
£1,083.33ex VAT£1,300.00 inc VAT
Regular price
£0.00
Sale price
£1,083.33ex VAT£1,300.00 inc VAT
Unit price
per
Price shown ex VAT and inc VAT (20%).
UK delivery £5.99, free on orders of £50 or more (inc VAT). Delivery details
Couldn't load pickup availability
✓ In stock: UK delivery in 2–4 working days
Overview
It is a switched rack PDU with a maximum current capacity of 30A and an input voltage of 208V. It includes 16 IEC C13 outlets and a NEMA L6-30P input connection. The PDU has a 2U form factor and a cord length of 12 feet. It supports remote monitoring and user-defined alarms, with outlet-level on/off switching capabilities. The unit is UL Listed and CSA certified, ensuring high safety and performance standards.
Specifications
Design
| PDU types | Switched |
|---|---|
| Rack capacity | 2U |
| Product colour | Black |
Ports & interfaces
| AC outlets quantity | 16 AC outlet(s) |
|---|---|
| AC outlet types | C13 coupler |
| Input connection type | NEMA L6-30P |
Features
| LED indicators | Yes |
|---|---|
| Cable length | 3.65 m |
Management features
| Monitoring | Current |
|---|---|
| Outlet control | Recycle, Turn off |
Power
| Nominal input voltage | 200; 208; 230 V |
|---|---|
| AC input frequency | 50 - 60 Hz |
| Maximum current | 30 A |
| Output voltage | 208 V |
| Maximum input current per phase | 30 A |
| Maximum total current draw per phase | 30 A |
Certificates
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
|---|---|
| Compliance certificates | RoHS, REACH, WEEE |
| Certification | cUL listed; CSA; Industry Canada; PSE; UL listed |
Operational conditions
| Operating temperature (T-T) | 0 - 45 °C |
|---|---|
| Storage temperature (T-T) | -25 - 65 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
Weight & dimensions
| Width | 445 mm |
|---|---|
| Depth | 254 mm |
| Height | 89 mm |
| Weight | 6.32 kg |
Technical details
| Sustainable packaging | No |
|---|---|
| Packaging recycled materials | Recycled cardboard |
| SCIP number | 1cdb2fed-a06f-4574-913d-8df8e70936b2 |
| Removable battery | Yes |
| Preferred mounting position | no preference |
| Take-back system | No |
| Packaging without single use plastic | No |
Product details
| Part number | AP7911B |
|---|---|
| Brand | APC |
| Supplier description | RACK PDU SWITCHED 2U 30A 208V 16X C13 |
| EAN | 0731304331605 |
