Overview A leap forward in professional-grade laptops from the number one vendor in commercial AI PCs worldwide. Featuring some of the thinnest, lightest, and quietest PCs in their class.
Specifications
Search the specifications
Design Colour name Magnetite Product type Laptop Product colour Black Form factor Clamshell
Display Display diagonal 35.6 cm (14") Display resolution 1920 x 1200 pixels Touchscreen No HD type Full HD+ Panel type IPS Native aspect ratio 16:10 Anti-glare screen Yes Display brightness 300 cd/m² Pixel density 162 ppi RGB colour space NTSC Colour gamut 45% Maximum refresh rate 60 Hz Contrast ratio (typical) 800:1
Processor Processor manufacturer AMD Processor family AMD Ryzen™ 5 PRO Processor generation AMD Ryzen PRO 200 Series Processor model PRO 230 Processor cores 6 Processor threads 12 Processor boost frequency 4.9 GHz Processor frequency 3.5 GHz L3 cache 16 MB L2 cache 6 MB
Neural processor unit (NPU) Neural processor unit (NPU) AMD Ryzen AI Total processor performance up to 31 TOPs NPU performance up to 16 TOPs
Memory Internal memory 16 GB Internal memory type DDR5-SDRAM Memory form factor SO-DIMM Memory layout (slots x size) 1 x 16 GB Memory slots 2x SO-DIMM Maximum internal memory 64 GB Memory data transfer rate 5600 MT/s
Storage Total storage capacity 512 GB Storage media SSD Total SSDs capacity 512 GB Number of SSDs installed 1 SSD capacity 512 GB SSD interface PCI Express 4.0 NVMe Yes SSD form factor M.2 M.2 SSD size 2230 (22 x 30 mm) Optical drive type No Card reader integrated No
Graphics Discrete graphics card model Not available On-board graphics card Yes Discrete graphics card No On-board graphics card model AMD Radeon 760M
Audio Audio chip Realtek ALC3204 Audio system High Definition Audio Number of built-in speakers 2 Speaker power 2.5 W Built-in microphone Yes Number of microphones 2
Camera Front camera Yes Front camera resolution (numeric) 2.07 MP Front camera resolution 1920 x 1080 pixels Front camera HD type Full HD Video capturing speed 30 fps Infrared (IR) camera Yes Privacy camera Yes Privacy type Privacy shutter
Network Top Wi-Fi standard Wi-Fi 6E (802.11ax) Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) Mobile network connection No Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 6 GHz) Wi-Fi data rate (max) 2400 Mbit/s Antenna type 2x2 WLAN controller model MediaTek MT7922 WLAN controller manufacturer MediaTek Ethernet LAN Yes Ethernet LAN data rates 10,100,1000 Mbit/s Bluetooth Yes MIMO Yes MIMO type Multi User MIMO
Ports & interfaces USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2 Ethernet LAN (RJ-45) ports 1 HDMI ports quantity 1 HDMI version 2.1 Thunderbolt 4 ports quantity 2 Intel® Thunderbolt 4 Yes Combo headphone/mic port Yes Power adapter barrel connector 4.5 mm USB Type-C DisplayPort Alternate Mode Yes PowerShare Yes Number of USB ports with PowerShare support 1
Performance Keyboard Pointing device Touchpad Numeric keypad No Keyboard backlit Yes Keyboard language UK English Copilot key Yes
Software Operating system architecture 64-bit Trial software Activate Your Microsoft 365 For A 30 Day Trial Operating system installed Windows 11 Pro
Brand-specific features Brand specific technologies HDR Camera, TNR, Express Charge Boost capable
Battery Number of battery cells 3 Battery capacity 55 Wh Battery voltage 11.7 V Battery recharge time 4 h Fast charging Yes Battery weight 210 g
Power AC adapter frequency 50 - 60 Hz AC adapter input voltage 100 - 240 V USB Type-C charging port Yes USB Type-C required charging power (min) 45 W USB Type-C required charging power (max) 65 W USB Power Delivery (USB PD) Yes USB charging voltage 5,9,15,20 V
Security Cable lock slot Yes Cable lock slot type Wedge Fingerprint reader Yes Face recognition Yes Trusted Platform Module (TPM) Yes Trusted Platform Module (TPM) version 2.0
Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -40 - 65 °C Operating relative humidity (H-H) 0 - 90% Storage relative humidity (H-H) 0 - 95% Operating altitude -15.2 - 3048 m Non-operating altitude -15.2 - 10668 m Operating shock 140 G Operating vibration 0.66 G
Weight & dimensions Width 313.7 mm Depth 225.3 mm Height (front) 1.89 cm Height (rear) 2.04 cm Weight 1.36 kg
Carbon footprint Total carbon footprint (kg of CO2e) 142 Carbon emissions, manufacturing (kg of CO2e) 114.17 Carbon emissions, logistics (kg of CO2e) 3.41 Carbon emissions, energy usage (kg of CO2e) 22.86 Carbon emissions, end-of-life (kg of CO2e) 1.42 PAIA version GaBi version 1, 2024
Other features Surface treatment textured
Product details Part number R26W7 Brand DELL Supplier description SPL PRO 14 PC14255 AMD RYZEN 5 230 16/512GB 14IN W11P NO PSU EAN 5397184986769
