Made for team collaboration, this monitor provides up to 90W power delivery via USB-C and flexibility to include an OptiPlex Micro based on your needs.
Specifications
Display
Panel type
IPS
LED backlight
Yes
LED backlighting type
Edge-LED
Display diagonal
138.8 cm (54.6")
Display technology
LCD
Display resolution
3840 x 2160 pixels
Display brightness
400 cd/m²
HD type
4K Ultra HD
Touchscreen
No
Native aspect ratio
16:9
Response time
8 ms
Contrast ratio (typical)
1200:1
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Display number of colours
1.07 billion colours
Pixel pitch
0.315 x 0.315 mm
Active display area (W x H)
1209.6 x 680.4 mm
Display diagonal (metric)
138.787 cm
Horizontal scan range
30 - 140 kHz
Vertical scan range
24 - 75 Hz
Supported graphics resolutions
640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1152, 2560 x 1440, 3840 x 2160
Supported video modes
480p, 576p, 720p, 1080i, 1080p, 2160p
Colour depth
8 bit
Haze rate
25%
Surface hardness
3H
Colour gamut
72%
Ports & interfaces
HDMI ports quantity
2
HDMI version
2.0
DVI port
No
DisplayPorts quantity
2
DisplayPort version
1.4
USB port
Yes
USB version
3.2 Gen 1 (3.1 Gen 1)
USB connector type
USB Type-A, USB Type-B, USB Type-C
USB 2.0 Type-B ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
2
USB Power Delivery (USB PD)
Yes
USB Power Delivery up to
90 W
USB Type-C DisplayPort Alternate Mode
Yes
Ethernet LAN (RJ-45) ports
1
RS-232C
Yes
DC-in jack
Yes
Audio
Built-in speaker(s)
Yes
Number of built-in speakers
2
RMS rated power
20 W
Design
Product design
Digital signage flat panel
Placement supported
Indoor
Product colour
Black
VESA mounting
Yes
Panel mounting interface
300 x 400 mm
Bezel width (bottom)
2.85 cm
Bezel width (side)
1.89 cm
Bezel width (top)
1.89 cm
Anti-glare screen
Yes
Performance
Purpose
Commercial
Power
Power consumption (typical)
77.1 W
Power consumption (standby)
0.5 W
Power consumption (off)
0.3 W
Power consumption (max)
300 W
Energy efficiency class (SDR)
E
Energy consumption (SDR) per 1000 hours
77 kWh
AC input voltage
100-240 V
AC input frequency
50/60 Hz
Weight & dimensions
Width
1247.4 mm
Depth
79.8 mm
Height
727.8 mm
Weight
22.4 kg
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80%
Storage temperature (T-T)
-20 - 60 °C
Storage relative humidity (H-H)
5 - 90%
Carbon footprint
Total carbon footprint (kg of CO2e)
927
Carbon emissions, manufacturing (kg of CO2e)
377.29
Carbon emissions, logistics (kg of CO2e)
63.04
Carbon emissions, energy usage (kg of CO2e)
373.58
Carbon emissions, end-of-life (kg of CO2e)
112.17
PAIA version
GaBi version 1, 2024
Network
Ethernet LAN
Yes
Technical details
Sustainability certificates
ENERGY STAR, TCO
Doesn't contain
Arsenic, Mercury, PVC/BFR
Compliance certificates
RoHS
Other features
Quick start guide
Yes
Remote control battery
AAA x 2
Product details
Part number
DELL-P5525QC
Brand
DELL
Supplier description
55IN 4K CONFERENCE ROOM MONITOR - P5525QC
EAN
0884116469438
In the box
Remote control included: Yes
Cables included: AC, DisplayPort, HDMI, USB, USB Type-C
