Samsung VM55B-U LED Indoor

Display

• Display technology: LED
• Pixel pitch: 0.63 x 0.63 mm
• Display brightness: 500 cd/m²
• Display diagonal: 139.7 cm (55")
• Display resolution: 1920 x 1080 pixels
• HD type: Full HD
• Panel type: IPS
• Contrast ratio (typical): 1200:1
• Contrast ratio (dynamic): 45000:1
• Response time: 0.008 s
• Viewing angle, horizontal: 178°
• Viewing angle, vertical: 178°
• Horizontal scan range: 62.7 - 72.3 kHz
• Vertical scan range: 57 - 63 Hz
• Haze rate: 25%
• Colour gamut: 72%
• Operating hours (hours/days): 24/7

Design

• Placement supported: Indoor
• Orientation: Horizontal/Vertical
• Bezel width (top): 2.25 mm
• Bezel width (bottom): 1.25 mm
• Wall mountable: Yes
• VESA mounting: Yes
• Panel mounting interface: 600 x 400 mm
• Product colour: Black

Ports & interfaces

• HDMI ports quantity: 2
• HDMI input ports quantity: 2
• HDMI version: 2.0
• DVI port: Yes
• DVI-D ports quantity: 1
• DisplayPorts quantity: 1
• DisplayPorts in: 1
• DisplayPort version: 1.2
• Ethernet LAN: Yes
• Ethernet LAN (RJ-45) ports: 1
• RS-232 input ports: 1
• RS-232 output ports: 1
• USB port: Yes
• USB ports quantity: 1
• HDCP: Yes
• HDCP version: 2.2
• IR input ports quantity: 1
• Audio input: Yes
• Audio output: Yes

Power

• Power consumption (typical): 220 W
• Power consumption (standby): 0.5 W
• Energy efficiency class (SDR): G
• Energy consumption (SDR) per 1000 hours: 165 kWh
• AC input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz

Operational conditions

• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): 10 - 90 °C

Sustainability

• Certification: FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 ? EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14

Weight & dimensions

• Width: 1213.5 mm
• Depth: 73.1 mm
• Height: 684.3 mm
• Weight: 21.2 kg

Packaging data

• Mounting kit: Yes
• Package width: 1398 mm
• Package depth: 257 mm
• Package height: 844 mm
• Package weight: 28.8 kg
